PEL has decades of in-house expertise in the production, diagnostics and modelling of microwave-driven plasmas. This know-how is crucial to foster advances in the recently emerging cutting-edge field of Plasma Nanoscience, and enabling the proposal of novel plasma-based technologies.
The PEL team uses state-of the-art equipment for producing microwave plasmas and for its characterisation with optical diagnostics, mass spectrometry and probes. The most relevant equipment is shown below.
VUV range 8 – 32 nm (550 g/mm grating) and 30 – 125 nm (1800 g/mm grating) 2 diffraction gratings; PMT and VUV sensitive silicon detectors and its data acquisition.
200 amu range; Faraday cup and electron multiplier detectors; input pressure up to 1 mbar.
Primary (dry) and turbomolecular pumps
Range from 5000 to 50 cm-1 (depending on the chosen beam-splitter, source, and detector)
Internal mirror to enable emission spectroscopy
Spectrometer: 0 – 1500 nm; 0.006 nm resolution @ 313 nm (1200 g/mm grating; 500 nm blaze) and 0 – 750 nm; 0.003 nm resolution (2400 g/mm grating)
CCD: LN2 cooled; 2500 x 1250, 8 mm pixels; 200 – 1050 nm
PMT: ambient temperature; 185 – 900 nm
Two 120 x 140 mm diffraction gratings; PMT detector, CCD camera and their data acquisition
Pump Laser: 20 Hz repetition rate; 355 mJ @ 1064 nm; 160 mJ @ 532 nm; 70 mJ @ 355 nm
Dye Laser: 200 – 900 nm (depending on dye and configuration); 35 mJ @ 562 nm (peak of Rh590 dye); 7.5 mJ @ 281 nm (doubling, Rh590 dye); 0.8 mJ @ 222 nm (mixing after doubling, Rh50 dye); 20 mJ @ 615 nm (peak of Rh640+DCM dye); 7 mJ @ 307 nm (doubling, Rh640+DCM dye); 0.4 mJ @ 205 nm (tripling, Rh640+DCM dye); 4.5 mJ @ 510 nm (peak of C500 dye)
2.45 GHZ [2 x Sairem GMP 20K; 1 x Sairem GMP 20 KED; 1 x GMP 12 KTS]: 3 x 2 kW (2 x CW; 1 x CW or pulsed; 0.1 ms rise and fall time), 1 x 1.2 kW
200 –700 MHz [EPSCO EP250C w/ M8045H head]: 250 W
10 kHz – 200 MHz [RF POWER LABS 220 – 200LD]: 200 W
Includes waveguide components (straights; E- and H-curves); power meters; circulators; matching devices; short-circuits; wave launchers (Robox, surfatrons; waveguide surfatrons)
